Description
On the line,within the triangle belt,speed reducer,slowly gear drive the impeller,motor is rotating.Sand through the feed tank into the wash tank,rolling by the impeller,then mutual lapping to remove the sand surface impurities.For another,it ass water and from a strong current so as to take away impurity and the small foreign body timely,then discharge from the wash tank,complete the meaning.Clean sand flows away by blade,the remaining sandstone throgh rotating impeller to discharge to complete sand cleaning.
Technical Parameter:
Model
Impeller Size
Impeller Speed (R/MIN)
Capacity
(T/H)
Sufi Size(MM)
Power
(KW)
Water Requirement
(T/H)
XSD2610
Ø2600X1000
1.178
20-50
≤10
5.5
10-80
XSD2816
Ø2800X1600
1.177
30-60
11
20-60
XSD3016
Ø3000X1600
1.179
50-120
15
20-150
XSD3620
Ø3600X2000
1.180
80-150
18.5
40-300
