Description
This series bag filter has many advantages,like strong ability and high efficiency of dust removing,low emission concentration,less air leakage rate,low energy and steel consumption,small occupation area,reliable operation,and good economic benefit,etc.And it is mainly used for purifying the dusty gas and recycling materials,widely applied in metallurgy,construction materials,cement,machinery,chemical,electricity and light industries.
Technical Parameter:
|
Model |
Air Flow Rate (㎡/H)
|
Total Filter Area(㎡)
|
Chamber Q’ty (PCS) |
Quantity of Filter Bags (PCS) |
Pulse Valve |
Compressed Air Consumption (N. m³/MIN) |
Weight (Excluding Insulating Layer) |
|
|
Quantity (PCS) |
Spec. (Inch) |
|
|
|||||
|
PPC32-4 |
8930 |
124 |
4 |
64 |
4 |
2½ |
0.37 |
3400 |
|
PPC32-6 |
13390 |
186 |
6 |
6 |
0.55 |
5400 |
||
|
PPC64-4 |
17800 |
248 |
4 |
4 |
1.2 |
6900 |
||
|
PPC64-6 |
26700 |
372 |
6 |
6 |
1.8 |
9700 |
||
|
PPC64-8 |
35700 |
496 |
8 |
8 |
2.4 |
12500 |
||
|
PPC96-4 |
26800 |
372 |
4 |
96 |
4 |
3” |
1.2 |
8710 |
|
PPC96-6 |
40100 |
557 |
6 |
6 |
1.8 |
12400 |
||
|
PPC96-8 |
53510 |
744 |
8 |
8 |
2.4 |
15700 |
||
|
PCC96-12 |
80400 |
1023 |
12 |
12 |
3.4 |
25200 |
||
|
PPC128-6 |
67400 |
936 |
6 |
128 |
6 |
3.5 |
20100 |
|
|
PCC128-8 |
89870 |
1248 |
8 |
8 |
4.8 |
28900 |
||
|
PCC128-10 |
112100 |
1558 |
10 |
10 |
6.0 |
28900 |
||
